5V 2004 20X4 204 2004A Lcd Display Module Blue Screen For Arduino
5V 2004 20X4 204 2004A LCD Display Module Blue Screen For Arduino Description : The 2004A character LCD module is designed to display letters, numbers, symbols, dot matrix. It can display 4 lines of 20 characters. Support 4-bit and 8-bit data transfer mode. Offers 5x7 matrix cursor display mode. Providing display data buffer DDRAM, character generator CGROM and CGRAM. CGRAM can be used to store up to eight 5x8 dot matrix character font data graphic own definition. Provides a rich instruction set : clear display, cursor back to origin, display on / off, cursor on / off, display character blink, cursor shift, display shift and so on. Specification : Module size(W x H x T) : 98.0 x 60.0 x 14.0mm Viewing area(W x H) : 76.0 x 26.0mm Character size(W x H) : 2.94 x 4.74mm Dot size : (W x H) : 0.54 x 0.54mm LCD type en color : STN(Blue), FSTN View angle : 6 Oclock Display type : positive / negative type Control IC en package : KS0073 or EQV, COB Operating temperature : -20 graden C - 70 graden Lees meer over de 5V 2004 20X4 204 2004A Lcd Display Module Blue Screen For Arduino van huismerk in de productgroep elektronica
5,95
| Merk | huismerk |
| verzendkosten | 0.00 |
| artikelnummer | dd915064 |
| voorraad | -1 |
| Levering | Bezorgen of afhalen |
| Staat | Nieuw en Tweedehands |
| Aanbieding | Bekijk de prijs |
